Phase Ranger

Analog Phase Shifter | Dealer Exclusive
Download the Manual

SKU#: P48

IT’S NOT JUST A PHASE

Phase Ranger is an analog phase shifter pedal offering two distinct varieties of classic, vintage-inspired modulation in an easy-to-use, micro package. At the heart of Phase Ranger is an octet of precision-matched VCAs that produce silky smooth linear phase shifting with remarkable dynamic range, low-noise performance and crystal clear sound. Standard knobs for Speed and Depth dictate the rate and intensity of the syrupy phase tone offered by Phase Ranger. The two LFO controls are joined by a single, push-button toggle switch that selects either 4-stage or 8-stage phase shifting. The 4-stage mode takes you straight to the late 1970’s with a wide-open, groovy sound. The 8-stage mode creates a more complex and detailed phaser previously found only in high-end studio gear from the glory days of analog synthesis. Available exclusively at Guitar Center.

Features
Features
Specs & Compare
Videos

KNOB-BY-KNOB

Depth: Sets the intensity of modulation.

Speed: Sets the rate of modulation.

Stage: Selects either 4-stage or 8-stage phaser modes. Green = 4-stage. Red = 8-stage.

TAKE THE STAGE

With the ability to toggle between 4-stage and 8-stage phase shifting, Phase Ranger allows you to achieve a broad, modern phase effect as well as vivid, detailed phasing previously available only in vintage rack gear.

SHIFTING MOODS

While exploring a vast, canyon-like planet where it is always dusk, Marvin built the Phase Ranger—a vehicle that navigates uneven terrain and trippy topology with ease.

Phase Ranger

Compare another model

MODEL

Model Name
Phase Ranger
SKU
P48
Function
Category 1
Modulation
Category 2
-
Expression
-
Bypass
True Bypass

ELECTRONICS

Voltage
9VDC
Current Draw
100mA
Input Impedance
2.2M
Output Impedance
150ohms

BODY

Length (in)
1.5
Width (in)
3.75
Height (in)
1.75
Weight (lbs)
0.5
